100X REMOTE CONTROL BALL FLOAT

Product profile

The 100X remote controll float valve is a hydraulically operated valve with multiple functions. lt is mainly installed in thewater inlet of the pool or elevated water tower, When the water level reaches the set height, the main valve is controlled by thefloat pilot valve to close the water inlet and stop the water supply, When the water level drops, the main valve is controlled by thefloat switch to open the water inlet and inject water into the pool to realize automatic water replenishment. Precise liquid levelcontrol, free from water pressure interference: 100X remote control float valve can be installed, maintained, adjusted andinspected at any position with the height of the pool and the use space, reliable sealing and long service life.

Working principle

When the pipeline is fed water from the inlet end, because the needle valve, ball valve and float valve are normally openwater enters the pool through the needle valve, control room, ball valve and float valve. At this time, no pressure is formed in thecontrol room, the main valve is opened, and the water tower (pool) is supplied.When the water rises to the set height, the float ball will be closed, Pressure rises in the main control room, push the mainvalve to close, and stop the water supply. When the water level drops, the float ball valve is reopened, then the pressure dropsand the main valve is reopened to continue the water supply and maintain the set Liquid level.

Typical installation Diagram.
